Gear Pump ALHP2-B2-X-7-T1-F1
-
Code:5330001980
-
Weight:2.200 Kgs
Group two Displacement 8 cm3 Max Pressure 270 bar Max speed 4000 r/min Min speed 500 r/min
M6 threads depth 13. To mount the pump, n.4 M10 screws, with a torque wrench setting fixed at 70...75 Nm. Shaft M12x1.5 nut, with a torque wrench setting fixed at 50 Nm.
| File | Info |
|---|---|
зъбна помпа amberline pdf
|
[PDF, 485.65 KB] |
